Alamar: Tasarzal
Yawan aiki: 1250k
Wurin Bayani: Shenzhen
Certificate: CE/ROSH/UL/ISO9001
Shenzhen Risingstar 10.1 Inch 1000 NIT TFT LCD, Inue / Boe / Bee / Bee / Innoe Haɗin LCD tare da kwamitin da LCD tare da kwamitin dubawa ta hanyar kwamiti. Daban-daban lcd suna amfani da siffofin dubawa daban-daban. Risingstar 10.1 Inch 1000 nits TFF LCD Panel ne yafi Lvds ke dubawa.
Mahaifa
| Size | 10.1inch |
| Panel item | RS101NET-N10 |
| Panel type | a-Si TFT-LCD |
| Display mode | IPS,Normally black，transmissive display |
| Pixels | 1280*800 |
| brightness | 350-1000cd/m2 |
| Constrast Ratio | 800:1 |
| Response Time | 14/11ms |
| View angle | 85/85/85/85 |
| View area | 218.96*137.6mm(H*V) |
| Dispaly area | 218.96*137.6mm(H*V) |
| Outline Size | 230.7*152.55*7mm(H*V*D) |
| Signal Type | LVDS |
| Working freqyency | 60Hz |
| Working temperature | -20~70ﾟC |
| Storage Temperature | -25~70ﾟC |
| Display ratio | 16:9 |
| Display color | 16.7m |
| Backlight Voltage | 3.3V |
| Backlight Power Consumption | 6.18w |
| Surface Treatment | Haze |
| Weight | 0.375kgs |
