Model No.: BA104S01-100
Ba1044S01-100 shine samfurin LCD mai shigowa 10.4 (Boe) Amfani da Fasahar LCD na A-SI. An sanye shi da WLEL FASAHA, babu abin rufe fuska kuma ba taɓa taɓa ba. BA1044S01-100 (RGB) × 600 (SVGA), Matsayi na 4: 3 (nisa), da kuma ƙayyadadden samfurin) na RGB, da kuma ƙayyadadden samfurin tare da sigar No. Rev .1 Saki by Boe a ranar 12 ga Disamba, 2014. Nunin yankin shine 215.0 × 168.0 × 162.0 × 162.0 × 165.0 (fadi ne na gani) × 5.9 (kauri) mm, jiyya na farfajiya ya bayyana sarai, siket ɗin kayan aiki shine 288G (Tyw.). Bayar da baya wannan samfurin yana amfani da tushen shigarwar hasken 6s6p, rayuwar wutar lantarki ita ce sau 50k, babu abin hawa. Ba1044S01-100 Kompts Lvds (1 ch, 6/2-bit Matsayi na al'ada a tsaye mai ban sha'awa FV NE 60Hz. Yana aiki da AT -20 ° C zuwa 70 ° C da adana AT -30 ° C zuwa 80 ° C. Ana bada shawarar wannan ƙirar don amfani a masana'antu da likitanci saboda sa'o'i 50,000 na rayuwa, faɗakarwa na zamani, da sauran fasali na tilas.
| brand | BOE | Model name | BA104S01-100 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 800(RGB)×600 [SVGA] 96PPI | Pixel configuration | RGB vertical bar |
| Display Area | 211.2×158.4 mm (H×V) | Surface treatment | Clear |
| Visual size | 215.0×162.0 mm (H×V) | Contrast Ratio | 800:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 236×176.9×5.9 mm (H×V×D) |
| Viewing Angle | 70/70/60/70 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 6/8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
Wadannan nau'ikan iri ɗaya ne da sigogi
| brand | BOE | Model name | AV104X0M-N10 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 (XGA) 123PPI | Pixel configuration | RGB vertical bar |
| Display Area | 210.4 × 157.8 (H×V) mm | Surface treatment | / |
| Visual size | 215.4 × 161.8 (H×V) mm | Contrast Ratio | 1100:1 (Typ.) (TM) |
| Brightness(cd/m²) | 600cd/m²(Typ.)or customized | Outline dimension | 230 × 180.2(H×V) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 6/8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -40 to 95 °C Operation Temperature: -30 to 85 °C |
| brand | BOE | Model name | TDA104-001V02 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 (XGA) 123PPI | Pixel configuration | RGB vertical bar |
| Display Area | 210.4 × 157.8 (H×V) mm | Surface treatment | / |
| Visual size | / | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 900cd/m²(Typ.)or customized | Outline dimension | 235×173×10.5mm(H×V×D) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -55 to 85 °C Operation Temperature: -40 to 80 °C |
Sch. LCD allon don waje , LCD Panel, LCD Module, Nunin Haske mai tsayi.
