Abubuwan Samfuran

Model No.: TDA150-005V01

Marufi & Isarwa

Sayar da Rukuni:

Piece/Pieces

Gabatarwar Samfurin

Tda150-005v01 A-S TFT-LCD 15-inch ruwa crystal module, abubuwa na yau da kullun sune Fadakar shakatawa, gami da direban LED, farfajiya. Zazzabi mai aiki shine -20 ° C, kuma yawan zafin jiki yana -30 ° C. Ƙudurin nuna shine 1600 (RGB) × 1200 (Uxga), kuma ana shirya pixton a cikin RGB a tsaye. Girman yankinsa shine 304.8 × 228.6 (w × h) mm, kuma girma na waje shine 312.4 (w) × 242 (h) × 242 (h) mm.

Tushen haske ne mai haske tare da lifepan na awanni 30k, gami da direbobi da direbobi. Tda150-005v01 ya dauki Lvds (2 ch, 8-bit in dubawa, duka fil na lantarki shine 3.3V.).

15-2

Tambaya: Wanene mu?

A: R-star ya samo asali ne daga Shenzhen, China, mu ne gwani masana'antu mai tsayi na lcd, za mu iya samarwa daga 10.1 zuwa 120 inch inch, ciki har da ma'aikata 100, ciki har da injiniyoyi 20 da suka kware. Kamfanin ya wuce Iso9001 / ISO14001 / CCC / CE / FCC / CCC Amurka, Afirka, Gabas ta Tsakiya, Turai, Tsakiya, Kudancin Amurka da Oceania.we sun yi imani da cewa idan ka ba mu damar yin hidima, za mu zama mai ba da amintattu a kasar Sin.

Tambaya: Shin kuna masana'anta (masana'anta)?

A: Ee, muna. Hakanan ana samun sabis na OEM / ODM don raba ra'ayin ku tare da mu. Jin daɗinmu don samar da mafita mafi kyau a gare ku.

Tambaya: Ta yaya za mu tabbatar da inganci?

A: Kullum bincike na karshe kafin jigilar kaya.

brand	BOE	Model name	TDA150-005V01
size	15 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1600(RGB)×1200 [UXGA] 133PPI	Pixel configuration	RGB vertical bar
Display Area	304.8×228.6mm (H×V)	Surface treatment	Fog surface(Haze 25%)，Hard coating (3H)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Contrast Ratio	1000:1 (Typ.) (TM)
Viewing Angle	85/85/85/85 (Min.)(CR≥10)	Outline dimension	317.4 × 242 mm (H×V)
Signal interface	LVDS (2 ch, 8-bit) ,erminal, 40 pins
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C

Iri ɗaya da ƙira kamar haka:

brand	BOE	Model name	RT150X0M-N10
size	15 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1024(RGB)×768, XGA, 85PPI	Pixel configuration	RGB vertical bar
Display Area	304.8×228.6mm (H×V)	Surface treatment	Fog surface(Haze 25%)，Hard coating (3H)
Brightness(cd/m²)	1100cd/m²(Typ.)or customized	Contrast Ratio	1000:1 (Typ.) (TM)
Viewing Angle	80/80/80/80 (Min.)(CR≥10)	Outline dimension	326.5×253.5(H×V)
Signal interface	LVDS (1 ch, 8-bit) ,erminal, 20 pins
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C

brand	BOE	Model name	DV150X0M-N16
size	15 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1024(RGB)×768, XGA, 85PPI	Pixel configuration	RGB vertical bar
Display Area	304.128×228.096(H×V) mm	Surface treatment	Fog surface(Haze 25%)，Hard coating (3H)
Brightness(cd/m²)	600cd/m²(Typ.)or customized	Contrast Ratio	1000:1 (Typ.) (TM)
Viewing Angle	89/89/89/89(Min.)(CR≥10)	Outline dimension	326.5×253.5×9.7mm(H×V×D)
Signal interface	20 pins LVDS (1 ch, 8-bit) , erminal
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C

brand	BOE	Model name	RV150U0M-N00
size	15 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1600(RGB)×1200 [UXGA] 133PPI	Pixel configuration	RGB vertical bar
Display Area	304.8 × 228.6 mm (H×V)	Surface treatment	Fog surface(Haze 25%)，Hard coating (3H)
Visual size	307.2 × 231 mm (H×V)	Contrast Ratio	1000:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	317.4×242 mm(H×V×D)
Viewing Angle	85/85/85/85(Min.)(CR≥10)
Signal interface	LVDS (2 ch, 8-bit),40 pins, erminal
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C

Sch. Allon nesa, 15 4 TFD LCD , allon LCD, LCD Panel, LCD Module, Nunin Haske mai tsayi.

12.3 "AV123Z7M-N11 Haskaka LCD module

21.5 15 "Boe UV215FHM-N10 TFD LCD Panel Module

Boe Tda150-005v01 15 "Nunin Allon
