Model No.: LQ150X1LG96
Aikin zazzabi na LQ150x1lg96 shine 0 ~ 65 ° C, kuma zazzabi ajiya shine -30 ° C. Ya dace da aikace-aikacen masana'antu, karin bayanai na waje, wasanni. Jiyya na farfajiya yana matte, mai wuya mai ƙarfi (3h), da kuma siket na samfurin shine 950g (max.). A cikin sharuddan hasken rana, tushen hasken gefen-gefe yana da gidan zama na awanni 30k.
Tsarin Nunin LQ150X1L1LG96 shine 1024 (RGB) × 768 (XGB), an shirya yanayin matsayi na hannu 4: 3 (nisa: tsayi), kuma ana shirya pixels a cikin RGB tsaye a tsaye. Girman yanki na LQ150x1lg96 shine 304.128 × 228.096 (w × 23.10 (w) (w) × 10.1 (w) × 10.1 (w) × 10.1 (w) × 10.1 (w) × 10.1 (w) × 10.1 (w) × 10.1 (w) × 10.1 (w) mm.
| brand | Sharp | Model name | LQ150X1LG96 |
| size | 15inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 [XGA] 85PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.128×228.096mm(H×V) | Surface treatment | Fog surface，Hard coating (3H) |
| Visual size | 307.2×231.1mm(H×V) | Contrast Ratio | 800:1 (Typ.) (TM) |
| Brightness(cd/m²) | 1050cd/m²(Typ.)or customized | Outline dimension | 326.5×253.5×10.1 mm(H×V×D) |
| Viewing Angle | 80/80/60/80 (Typ.)(CR≥10) | work environment | Storage temperature: -30 to 70 °C Operation Temperature: 0 to 65 °C |
| Signal interface | LVDS (1 ch, 6/8-bit),erminal,20 pins |
|
|
| supply voltage | 3.3V (Typ.) |
|
|
Sch. "15Ch Sharp LQ150x1lg96 TFT LCDs Panel, 21 5 inci, Screenction Screen Burtaniya, nuni da allo na TV, Nuna allo UK, A waje kwamital 2500, 'ya'yan biyu , LCD Panel, LCD Module, Nunin Haske mai tsayi.
