Alamar: Tasarzal
Yawan aiki: 160K
Wurin Bayani: Shen Zhen
Certificate: CE/ROSH/UL/ISO9001
| Panel Brand | RISINGSTAR | Panel Model | RS220WPM-NE10 |
| Panel Size | 22.0" | Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 1680(RGB)×1050, WSXGA+, 90PPI | Pixel Format | RGB Vertical Stripe |
| Display Area | 473.76(W)×296.1(H) mm | Bezel Opening | 477.7(W)×300.1(H) mm |
| Outline Size | 493.7(W)×320.1(H) ×10.7(D) mm | Surface | Antiglare (Haze 25%), Hard coating(3H) |
| Brightness | 1000nit or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) | Display Mode | TN, Normally White, Transmissive |
| Display Colors | 16.7M 72% NTSC | Response Time | 1.5/3.5 (Typ.)(Tr/Td) |
| Frequency | 60Hz | Lamp Type | 3 strings WLED , 40K hours , Without Driver |
| Weight | 1.83Kgs (Typ.) | Input Voltage | 5.0V (Typ.) |
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins Connector | ||
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -25 ~ 60 °C | ||
RS220WPM-NE10 shine hasken rana 22 inch da ake kira wanda ke goyan bayan duniyar Lvds. Zai iya aiki a yanayin zafi daga -20 ~ 70 ℃ da yanayin yanayin zafi ya kasance daga -30 ~ 80 ℃. RS220WPM-NE10 shine 1000 Nits mai tsayi da TFF LCD. Ya dace da kayan aikin masana'antu, na'urorin hannu, kayan aikin likita, kayan aikin waje, waje da yanayin waje.
Fasas
1. Haske mai haske, babban bambanci, lokacin amsawa mai sauri, tallafin launi mai launi, kusancin launi, kusurwar kallo.
2. Layin samar da ƙwararren ƙasa, miliyoyin muhalli na ƙura, jikin allo da led allo ya dace;
3. Takaddun shaida, FCC, CE, CCC, CC, Rohs;
4. Fasahar LED Badage
5. Tsarin Sturdy, tasirin anti-waje, Chassis na waje.
1. Kwararrun masu ƙwarewa na waje
2. Profesin karfi High-haske allo allon, na iya tsayayya 110 zazzabi mai zafi
3. Samsung, LG Beo, Auo, Kamfanonin Bulusin Innolux
4. Bayar da ku da Shafawar Fasaha ta waje da Shiriya
Tambaya: Zan iya sayan samfurin don oda na?
A: Ee, da fatan za a iya samun 'yanci don tuntuɓar mu.
Tambaya: Ta yaya za mu tabbatar da inganci?
A: koyaushe dubawa na karshe kafin jigilar kaya;
Tambaya: Menene fa'idodinmu?
A: low farashin samfuran inganci, bayanan da aka tsara a lokacin.
Tambaya: Har yaushe garanti ce?
A: Muna bayar da garanti ɗaya daga ranar isarwa.
Tambaya: Shin kana kasuwancin kasuwanci ne ko masana'anta?
A: Mu masana'anta ne.
